12v Potted 10 – 100cm2
Capacity: 10 – 100cm2 EL Panels
– or 5m of EL Wire
Dimensions: 1.8 x 2.4 x 2.8cm
Description
Small 12v Potted Inverter
This EL Inverter is suitable for up to 100square cm of EL Panel or 5 metres of EL Wire
It has been potted inside epoxy resin which keeps it water resistant as well as helping keep the whistle of transformer to a minimum
There is a choice of either a plunger switch on a 1.2m long cord
or if you choose ‘No Switch’ then it will come on when you attach it to a power source
(Please be aware that the inverter should always be attached to some EL Tape/Panel or EL Wire when it has power to it, else it may overheat)
The Inverter has 2.1/5.5mm jack plug – this is a standard 12v connector.
You will find these compatible Power Inputs options in the drop down selection:
Only the Inverter:
You may already have your own 12v input with a 2.1/5.5mm connector,
or you may choose to snip off the connector and wire it directly into a 12v source
This is usually the solution if you want to run the inverter off your own 12v battery
To make this inverter portable then just plug in this battery box.
.
Please note that rechargeable AA batteries are lower voltage than standard batteries so cannot really be used effectively with this battery box
These 18650 rechargeable batteries have now become popular and widely available. This Battery Box will plug straight into the driver and will make this EL Driver portable and rechargeable
These are smaller and lighter than the Battery Box, the 3000mAh Li-ion battery gives the same life as the 8xAA Battery Box with fresh alkaline batteries
1000mAh: 81g (6.5cm x 3.7cm x 1.8cm)
1800mAh: 145g (5.6cm x 3.8cm x 3.1cm)
3000mAh: 172g (7.3cm x 5.6cm x 2.2cm)
5000mAh: 265g (6.0cm x 5.8cm x 3.9cm)
All of these Li-ion Batteries come with an intelligent recharger
(*Li-ion Batteries are only available to the UK due to airmail postal restrictions)
This will convert mains electricity to 12v so it can be used as a handy input for this inverter
This adaptor plugs into the car lighter socket. It is fused and ends with a 5.5mm/2.1mm jack plug so it can be used with any of our 12v Drivers or accessories
All of these external power inputs, as well as extras such as 12v remote controllers, can be found in Additional Items
